Leveling Up Head Movement Detection: My Graduation Project Adventure

August 22, 2024 (2mo ago)

Leveling Up Head Movement Detection: My Graduation Project Adventure

Hey there, tech enthusiasts and curious minds! πŸ‘‹

So, I've been knee-deep in this wild ride called my university graduation project, and boy, do I have a story to tell! We've been on a mission to detect head movements using machine learning. Sounds simple, right? Well, buckle up, because it's been quite the rollercoaster! 🎒

Tilt head

The Initial Game Plan

We started off thinking, "Hey, let's use MediaPipe to grab some facial landmarks and train a model to figure out head movements!" Seemed straightforward enough. We were all pumped to detect tilting, turning, nodding – you name it!

Here's a snippet of how we initially extracted facial landmarks:

import cv2
import mediapipe as mp
import pandas as pd
import os

# Initialize MediaPipe Face Mesh
mp_face_mesh = mp.solutions.face_mesh
face_mesh = mp_face_mesh.FaceMesh(static_image_mode=True, max_num_faces=1, min_detection_confidence=0.5)

# Prepare DataFrame for landmarks
columns = [f"FACE_{i}_{axis}" for i in range(468) for axis in "XYZ"]
columns.append("Filename")
face_landmark_df = pd.DataFrame(columns=columns)

# Process images
for root, dirs, files in os.walk("PoseDataset"):
    for file in files:
        if file.startswith("."):
            continue

        image_path = os.path.join(root, file)
        image = cv2.imread(image_path)
        image_rgb = cv2.cvtColor(image, cv2.COLOR_BGR2RGB)

        results = face_mesh.process(image_rgb)

        if results.multi_face_landmarks:
            landmarks_data = []
            for landmark in results.multi_face_landmarks[0].landmark:
                landmarks_data.extend([landmark.x, landmark.y, landmark.z])

            landmarks_data.append(file)
            face_landmark_df.loc[len(face_landmark_df)] = landmarks_data

            # Save image with landmarks (optional)
            output_path = os.path.join("FaceOutput", os.path.relpath(root, "PoseDataset"), file)
            os.makedirs(os.path.dirname(output_path), exist_ok=True)
            mp.solutions.drawing_utils.draw_landmarks(
                image=image,
                landmark_list=results.multi_face_landmarks[0],
                connections=mp_face_mesh.FACEMESH_TESSELATION,
                connection_drawing_spec=mp.solutions.drawing_utils.DrawingSpec(color=(0,255,0), thickness=1)
            )
            cv2.imwrite(output_path, image)

# Save landmarks to CSV
face_landmark_df.to_csv("face_landmarks.csv", index=False)

face_mesh.close()

But here's where it gets interesting (or frustrating, depending on how you look at it πŸ˜…):

Houston, We Have a Problem

Houston, We Have a Problem

Our model was struggling harder than me trying to wake up for an 8 AM class. It just couldn't tell the difference between subtle movements. Tilting, turning – it was all the same to our poor, confused AI.

Confused

It almost feel like I need to crack my head to make it know I'm tilting my head. πŸ€¦β€β™‚οΈ

The Lightbulb Moment πŸ’‘

Then, out of nowhere, while I was probably procrastinating on TikTok, it hit me: "Why are we trying to make one model do everything? That's like asking your cat to fetch, do your taxes, and make you coffee!"

cat agent

Our Cool New Approach

Here's what we cooked up:

  1. Use MediaPipe as our base model (it's like the foundation of a house, but for faces)
  2. Create a bunch of smaller models, each with its own specialty (like having a different chef for each course in a fancy restaurant)
  3. Combine all their outputs for the final prediction (teamwork makes the dream work, right?)

It's kind of like how Apple does their AI magic, or how LoRA works in those fancy diffusion models. We're basically creating a boy band of AI models, each with its own special talent! πŸ•ΊπŸ•ΊπŸ•ΊπŸ•Ί

One more thing..

The Secret Sauce (a.k.a. How It Actually Works)

  1. MediaPipe: Our facial landmark detective πŸ•΅οΈ
  2. Specialized Models:
    • Tilt Detective πŸ”
    • Turn Tracker πŸ‘€
    • Nod Spotter πŸ‘
    • (and more – we got the whole squad!)
  3. The Mastermind: A module that takes all this info and makes the final call

Here's a sneak peek at how we're combining our models:

facing_model_seq = load_model('facing_direction_model.h5', compile=False)
motion_model_seq = load_model('tilt_turn_model.h5', compile=False)
up_down_model_seq = load_model('up_down_model.h5', compile=False)
facing_input = Input(shape=(468 * 3,), name='facing_input')
facing_output = facing_input
for layer in facing_model_seq.layers:
    facing_output = layer(facing_output)
facing_model = Model(inputs=facing_input, outputs=facing_output, name='facing_functional')

shared_input = Input(shape=(468 * 3,), name='shared_input')
facing_pred = facing_model(shared_input)
motion_pred = motion_model(shared_input)
up_down_pred = up_down_model(shared_input)

merged_output = Concatenate(name='combined_output')([facing_pred, motion_pred, up_down_pred])
combined_model = Model(inputs=shared_input, outputs=merged_output, name='combined_model')
combined_model.save('combined_model_with_up_down.h5')

Each specialized model (tilt_model, turn_model, nod_model) focuses on its specific task, making it much more accurate at detecting subtle differences.

Did It Actually Work?

Short answer: Heck yeah! πŸŽ‰

Long answer: We saw some serious improvements:

Check out these comparison results:

chart

What's Next?

Well, we're not stopping here! We've got big dreams:

We're also thinking about optimizing our model for mobile devices. Imagine having this running smoothly on your smartphone! πŸ“±βœ¨

The Big Takeaway

Breaking down big problems into smaller, manageable chunks? Total game-changer. It's like when you're faced with a huge pizza – tackle it slice by slice, and before you know it, you've conquered the whole thing! πŸ•

That's all for now, folks! Remember, in the world of AI and machine learning, sometimes the best solution is to divide and conquer. Stay curious, keep experimenting, and who knows? Your next crazy idea might just be the next big thing! ✌️


If you're curious, you can check out our multi-model approach here: https://huggingface.co/suko/Janus/
